Overview
Our 15.6" Industrial monitor is specially for outdoor or high brightness application, support 300-1500 nits brightness, with embedded design, touch function is optional.
Multi-point capacitive touch panel, support the Windows 7 , 8 ,& 10 , Linux & Raspberry pi 4. It’s widely used in indoor & outdoor applications, like ATM, Gas station, KIOSK,Vending machine, Express machine & Gaming.

Key specifications
* Open frame Embedded design (light design)
* 300/500/1000 /1500 nits brightness, sunlight readable.
* Outdoor application.



Model	SOP156H1-L1V2
Design	Open frame design .
LCD Type	15.6＂TFT-LCD ,16 : 9 screen
Recommend Resolution	1366(RGB)×768(WXGA)
Touch panel	Capacitive Touch ( 10 point) is optional
Brightness	300 /500/1000 nits optional
Light sensor	Brightness can be changed automatically, it's 1000 nits at day time, and turn to 400-500 nits at night, which will save the panel lifespan a lot.
Monitor interface Input	VGA +  HDMI
Contrast ratio	1000 : 1 (Typ.)
Viewing angle (v/h)	80°/80°/80°/80°
Operating System	Windows 7/8/10,Raspberry Pi
Mount Interface	1)VESA 75mm and 100mm 2)Mount bracket, horizontal or vertical
Touch interface	USB port
Mount Interface	VESA 75 & 100mm
Regular Warranty	1 year for LCD & components
