Overview
our 32" Industrial all in one touch PC is specially for outdoor application, it’s Waterproof & Sunglight readable, with high brightness (1000 nits -1500 nit  is optional). This 32 inch All in one pc is widely used in many applications, like ATM, Gas station, KIOSK,Vending machine, Express machine , Gaming & other terminal machines .
Multi-point capacitive touch panel is optional, support the Windows 7 , 8 ,& 10 , Linux & Raspberry pi 4 .
Different main board is provided, like J1900 ,intel i3 , i5 & i7 chip .

Key specifications
* Metal frame wateproof design . (OEM design is optional)
* 1000 -1500 nits brightness, sunlight readable.
* Waterproof & vandal-proof function
* J1900, i3 , i5 , i7 chip CPU is optional, 4G /8G RAM , 64G /120G /256G SSD is optional.


Model	AOW32CH1-L1i3G4
Design	Metal frame design
Waterproof	IP65, The whole unit is waterproof
LCD Type	32＂TFT-LCD ,16 : 9 screen ( IPS & TN )
Touch panel	Capacitive Touch ( 10 point) is optional
Recommend Resolution	1920(RGB)×1080
CPU	intel®Haswell-U I3-4120U/2.0GHz
Brightness	300/1000 /1500 nits optional
Light sensor	brightness can be adjusted automatically, it’s 1000/1500 nits at day time, and turn to 500-600 nits at night.
Video Card	Support DirectX® 10.1Support HD Graphics 4000 / HD-DVD  HD playback
Input Voltage	110-240 VAC
LCD Resolution	1920x1080
Contrast ratio	1400 : 1 (Typ.)
Viewing angle (v/h)	85°/85°/85°/85° full viewing angle
Operating System	Windows 7/8/10,Linux ,Ubuntu,Raspberry Pi
WIFI	Support
4G Module	Optional
Interface	2 x Audio jacks (Line Out, Mic In) 1 x HDMI port 1 x D-Sub (VGA) port 2-4 x USB port   2-4 x RS232 /COM 1 x LAN 1 x DC12V
Main board	Mini ITX 170x170mm
Power Supply	voltage: 12V DC, 50-60 Hz Output voltage/current: 12 volts at 4 amps max
