Embedded 1500 nits 18.5" 18.5 inch Open frame led monitor for Terminal Machine GAMING

2022-10-22 18.5 inch Open frame monitor

Overview
our 18.5" Open frame led monitor with high brightness (500 nits / 1000 nits/1500 nit), which is sunlight readable,specially for outdoor applications., like ATM, Gas station, KIOSK,Vending machine, Express machine , Gaming & different terminal machines .

Key specifications
*Embedded Open frame design( 15~32 inch is optional)
* 500 - 1000 -1500 nits sunlight readable, brightness can be changed automatically.
* Touch panel is optinal.

Model	SOP185H1-L1V2
Design	Open frame design
Screen size	18.5＂16: 9 screen,
Touch panel	Capacitive Touch ( 10 point) is optional.
Recommend Resolution	1366(RGB)×768(WXGA)
Brightness	500 -- 1000 -1500 nits optional
Light sensor	Can adjust the brightness automatically, it’s 1000 nits at day time, and turn to 400-500 nits at night.
Input Voltage	110-240 VAC
Contrast ratio	1000 : 1 (Typ.)
Interface	VGA + DVI (HMDI & AV is optional)
Touch port	USB port ( RS232 is optional)
Viewing angle (v/h)	85°/85°/85°/85° or 80°/80°/80°/80° viewing angle
Speaker	optional
Mount Interface	VESA 75& 100mm
Power Supply	voltage: 12V DC, 50-60 Hz Output voltage/current: 12 volts at 4 amps max
Regular Warranty	1 year for LCD & components
