Overview
our 23.6" Industrial All in one PC is sunlight readable, brightness can reach 500-1000-1500 nits,with light sensor function optional.This all in one pc is widely used in different outdoor embedded applications, like ATM, Gas station, KIOSK,Vending machine, Express machine & Gaming .

Key specifications
* Open frame design,is specially for embedded application.
* 500 - 1000 -1500 nits brightness optional, sunlight readable.
* Touch function is optional.
 * J1900, i3 , i5 , i7 chip CPU is optional, 4G /8G RAM , 64G /120G /256G SSD is optional.



Model	AO236CH1-SOJi3G4
Design	Open frame design
LCD Type	23.6＂TFT-LCD ,16 : 9 screen ( IPS & TN )
Touch panel	Capacitive Touch is optional
Recommend Resolution	1920(RGB)×1080
CPU	Intel®Haswell-U I3-4120U/2.0GHz
Chipset	Intel®Haswell-U/Broadwell-U SOC
Brightness	500 -- 1000 -1500 nits optional
Light sensor	Can adjust the brightness automatically, it’s 1000 nits at day time, and turn to 400-500 nits at night.
Video Card	Support DirectX® 10.1Support HD Graphics 4000 / HD-DVD  HD playback
Input Voltage	110-240 VAC
LCD Resolution	1920x1080
Contrast ratio	1400 : 1 (Typ.)
Viewing angle (v/h)	85°/85°/85°/85°  or 80°/80°/80°/80° full viewing angle
Operating System	Windows 7/8/10,Linux ,Ubuntu
WIFI	Support
4G Module	Optional
Interface	2 x Audio jacks (Line Out, Mic In) 1 x HDMI port 1 x D-Sub (VGA) port 2-4 x USB port   4-6 x RS232 /COM 1 x LAN 1 x DC12V 1x 25 pin printer connector ( Optional)
Main board	Mini ITX 170x170mm
Operating system	Windows 7/8/10
Power Supply	voltage: 12V DC, 50-60 Hz Output voltage/current: 12 volts at 4 amps max
