Overview our 15" Plastic frame touch screen monitor is widely used in POS machine,with good looking pure flat design. This 15 inch touchscreen monitor also support 300 -1000 nits.
Multi-point capacitive touch panel, support the Windows 7 , 8 ,& 10 , Linux & Raspberry pi 4 . Planar brings decades of rugged and extreme application display experience to touch screen monitors, making them the most dependable and well-performing on the market.
Key specifications
* Pure flat Plastic frame design, for POS machine .
* Multi point touch panel.
* Windows 7,8 & 10,Linux supported.
Model
| T1505C-P1V1
|
Design
| Plastic frame Pure flat design
|
LCD Type
| 15＂TFT-LCD , 5 : 4 screen ( IPS or TN )
|
Touch panel
| Capacitive Touch ( 10 point)
|
Recommend Resolution
| 1024(RGB)x768(SXGA)
|
Brightness
| 300 nits optional
|
Input Voltage
| 110-240 VAC
|
Contrast ratio
| 700 : 1 (Typ.)
|
Viewing angle (v/h)
| 85°/85°/85°/85° or 80°/80°/80°/80°
|
Operating System
| Windows 7/8/10,Raspberry Pi
|
Interface
| VGA (HMDI is optional)
|
Touch port
| USB port ( RS232 is optional)
|
Mount Interface
| VESA 75 & 100mm
|
Power supply
| 100-240 VAC, 50-60 Hz
|
Regular Warranty
| 1 year for LCD & components
|
