Overview our 21.5" professional Industrial monitors with high brightness (500 nits - 1000 nits), which is sunlight readable, can work outdoors. This 21.5 inch touchscreen monitor is widely used in different applications, like ATM, Gas station, KIOSK,Vending machine, Express machine & Gaming .
Multi-point capacitive touch panel, support the Windows 7 , 8 ,& 10 , Linux & Raspberry pi 4 . Planar brings decades of rugged and extreme application display experience to touch screen monitors, making them the most dependable and well-performing on the market.
Key specifications
* Good looking, pure flat design + aluminum alloy frame
* 500 - 1000 nits brightness, sunlight readable,
with light sensor function, which can change brightness automatically.* 3mm tempered glass, vandal-proof function, Anti-glare function is optional.
* Surface IP65,waterproof Model
| OPT215CH1-P2V2
|
Design
| Pure flat . Aluminum alloy + metal frame
|
LCD Type
| 21.5＂TFT-LCD ,16 : 9 screen
|
Recommend Resolution
| 1920(RGB)×1080
|
Touch panel
| Capacitive Touch ( 10 point) ,with 3mm tempered glass ( AG is optional)
|
Brightness
| 500 -- 1000 nits optional
|
Light sensor
| Can ajust the brightness automatically, it’s 1000 nits at day time, and turn to 400-500 nits at night.
|
Input Voltage
| 110-240 VAC
|
LCD Resolution
| 1920x1080
|
Contrast ratio
| 1000 : 1 (Typ.)
|
Viewing angle (v/h)
| 89°/89°/89°/89° or 80°/80°/80°/80°
|
Operating System
| Windows 7/8/10,Raspberry Pi
|
Interface
| VGA,HMDI ( DVI & AV is optional)
|
Touch interface
| USB port
|
Mount Interface
| VESA 100mm
|
Regular Warranty
| 1 year for LCD & components
|
