Overview our 32" professional Industrial monitors with high brightness (500 nits / 1000 nits/1500 nit), which is sunlight readable, can work outdoors. This 32 inch touch screen monitor is widely used in different applications, like ATM, Gas station, KIOSK,Vending machine, Express machine & Gaming .
Multi-point capacitive touch panel, support the Windows 7 , 8 ,& 10 , Linux & Raspberry pi 4 . Planar brings decades of rugged and extreme application display experience to touch screen monitors, making them the most dependable and well-performing on the market.
Key specifications
* Good looking, pure flat design + aluminum alloy frame . (OEM design is optional)
* 500 - 1000 -1500 nits brightness, sunlight readable, with light sensor function, can change brightness automatically.
* 3mm tempered glass, vandal-proof function, AG Anti-glare function is optional.
* Surface IP65,waterproof
Model
| OPT32CH1-P1V2
|
Design
| Pure flat . Aluminum alloy + metal frame
|
Waterproof
| Surface is IP65
|
LCD Type
| 2332＂TFT-LCD ,16 : 9 screen ( IPS & TN )
|
Touch panel
| Capacitive Touch ( 10 point) ,with 3mm tempered glass ( AG is optional)
|
Recommend Resolution
| 1920(RGB)×1080
|
Brightness
| 500 -- 1000 -1500 nits optional
|
Light sensor
| Can ajust the brightness automatically, it’s 1000 nits at day time, and turn to 400-500 nits at night.
|
Input Voltage
| 110-240 VAC
|
LCD Resolution
| 1920x1080
|
Contrast ratio
| 1000 : 1 (Typ.)
|
Viewing angle (v/h)
| 85°/85°/85°/85°
|
Operating System
| Windows 7/8/10,Raspberry Pi
|
Interface
| VGA,HMDI ( DVI & AV is optional)
|
Touch port
| USB port ( RS232 is optional)
|
Mount Interface
| VESA 100mm
|
Regular Warranty
| 1 year for LCD & components
|
